Basic Info.
Condition
New
Certification
ISO, CE, TUV
Material
Monocrystalline Silicon
Power
180W
Type
Flexible
Cell
Sunpower
Efficiency
22%
OEM
Available
Weight
3kg
Solar Cell
All Black, Flexible, Shingle Solar Panel
Product Name
180W Foldable Solar Panel
Charger Controller
PWM 10A/12V&24V
Connector
Mc4compatible
Output USB-a
5V/2A
Rated Output Power
180W
Max. System Voltage
100VDC
Cable
5m 14AWG/Optional
Output USB-C
5V/3A
Transport Package
2PCS/Carton
Specification
FPS-180W
Trademark
Flagsun
Origin
China. Jiangsu
HS Code
8541402000
Production Capacity
100MW/Year
Packaging & Delivery
Package Size
100.00cm * 50.00cm * 30.00cm
Package Gross Weight
5.000kg
Product Description
| Product specification | |
| Bag material | 1680D |
| Bag color | Camouflage color or OEM color |
| Open size( MM) | 2140x565 |
| Folding size (MM) | 565x440 |
| Foldinjg thickness (MM) | 60 |
| Net weight (KG) | 4.10 KG |
| Solar panel | |
| Solar Cell | Sunpower |
| Efficiency rate | 21.4% |
| Maximum power(Pm) (W) | 200 |
| Power Tolerance | ±5% |
| Voltage at max power(Vmp) (V) | 16.5V |
| Current at max power(Imp) (A) | 12.12A |
| Open circuit voltage(Voc) (V) | 19.47V |
| Short circuit current(Isc) (A) | 13.33A |
| Operating Temperature (ºC) | -20 to 50ºC |
| Maximum System Voltage (V) | 300V |
| Maximum Series Fuse Rating(A) | 30A |
| Standard Test Condtion | Irrandiance 1000W/Square MM Module temperature 25ºC,AM=1.5 |
| Warranty | Power is not less than 90% in 5 years |
| Resistances | 227g stell ball fall down from 1m height and 60m/s wind |
| Noct | 46ºC ± 2ºC |
| Current temperature coefficient | 0.05%/°C |
| Voltage temperature coefficient | - 0.35%/°C |
| Power temperature coefficient | - 0.45%/°C |
This product is a multifunctional solar charger, with DC18V and USB charger port built in regulator which can charge for 12V big battery,camera,vedio and 5V Iphone/Ipad, PDA, MP3, MP4, digital camera, video camera, PSP video games,iPhone,Blackberry,blue-tooth headset, IPOD etc
at one time .
