Basic Info.
Model NO.
QW192-270-FM
Size
215*100*55mm
Certification
KC, PSE, RoHS, CB, CE, SAA Rcm Ukca Bsmi Ices
Socket Type
Au/EU/UK/Us Plug
Recyclable
Recyclable
Input Voltage
100-240VAC 50/60Hz
Color
Black/Army Green
Transport Package
Corrugated Paper Packing Box
Specification
Weight: 1600± 10g(only body)
Trademark
QUAWIN/OEM
Origin
Shenzhen
HS Code
850431900
Production Capacity
50000 Pieces
Product Description
Quick Detail:
Brand Name:QUAWINModel Number:QW192-270-FM
Use:6S 18V/19.2V Lifepo4 battery pack
Type:Electric
Place of Origin:Guangdong China (Mainland)
Color:Black/Army green
Shell Material:Aluminium alloy
Input voltage:100-240VAC 50/60Hz with PFC
Output voltage:21.9V
Output current:27a(Max)
Output power:591.3W
Special Process: Spray Three Proof Paint
Electromagnetic compatibility: meets the requirements of GJB
Reliability: MTBF>=3000H
Optional features:The battery pack with super capacitor can be charged from 0V
Certification:CB CCC CE ETL FCC GS KC PSE SAA RCM UKCA BSMI ICES
Output Connector:Waterproof plug, Crocodile Clip, Aviation Connector, XLR, Ring terminal, Aviation Model plug, SAE Plug, Anderson Connector, Customized
Packaging & Delivery:
12pcs/Carton
Carton size: 535*315*280mm
Delivery Detail:sample within 7 work days,15~25 days for bulk order
Carton size: 535*315*280mm
Delivery Detail:sample within 7 work days,15~25 days for bulk order
Specifications:
6S 18V/19.2V Lifepo4 battery pack
Features:
• Charging mode:CC-CV(Constant Current-Constant Voltage)
• High efficiency and low power consumption
• Stabilized output and low noice
• Efficiency(at 100% load): >=90%
• Operating temperature:-40ºC ~ 65ºC
• Storage temperature:-40ºC ~ 85ºC
• Operating humidity:5%~90%RH
• It can be used in harsh environmental conditions, with electromagnetic capacitance, high precision of voltage regulation, rain proof, low temperature resistance and corrosion resistance.
Specification:
• Input:100-240VAC 50/60Hz with PFC
• Output:DC 21.9V
• Charging current:27a(Max)
• Dimensions (mm):215*100*55
• Weight:1600±10g(only body)
Safety protections:
• Over current protection
• Over voltage protection
• Short circuit protection
• Reverse polarity protection
• Anti- revert current protection
• Anti-spark protection
LED Indicator:
Waiting Mode:LED(GREEN) ON
Charging Mode:LED(BLUE) FLASH
Full Charged Mode:LED(GREEN) ON
Charge Error Mode:LED(RED) FLASH
Call us to know more details datasheet
| Typical Product Model | |||||
| Model | Input Voltage(V) | Battery Voltage(V) | Charging Voltage(V) | Charging Current(A) | |
| QW128-300-FM | LiFePO4 | AC 100~264V | 12.8(4S) | 14.6 | 30 |
| QW256-200-FM | 25.6(8S) | 29.2 | 20 | ||
| QW384-140-FM | 38.4(12S) | 43.8 | 14 | ||
| QW512-100-FM | 51.2(16S) | 58.4 | 10 | ||
| QW640-080-FM | 64(20S) | 73 | 8 | ||
| QW768-070-FM | 76.8(24S) | 87.6 | 7 | ||
| QW148-300-LM | Lithium | 14.8(4S) | 16.8 | 30 | |
| QW259-200-LM | 25.9(7S) | 29.4 | 20 | ||
| QW370-140-LM | 37(10S) | 42 | 14 | ||
| QW481-100-LM | 48.1(13S) | 54.6 | 10 | ||
| QW629-080-LM | 62.9(17S) | 71.4 | 8 | ||
| QW740-070-LM | 74(20S) | 84 | 7 | ||
| QW120-300-SM | Lead Acid | 12(1S) | 14.7 | 30 | |
| QW240-200-SM | 24(2S) | 29.4 | 20 | ||
| QW360-140-SM | 36(3S) | 44.1 | 14 | ||
| QW480-100-SM | 48(4S) | 58.8 | 10 | ||
| QW600-080-SM | 60(5S) | 73.5 | 8 | ||
| QW720-070-SM | 72(6S) | 88.2 | 7 | ||
