Basic Info.
Model NO.
MP-12100
Size
Small
Rated Voltage
12.8V
Rated Capacity
200ah
Rated Energy
2560wh
Max. Charge Voltage
14.6V
Max. Charge Current
100A
Max. Discharge Current
100A
Peak Discharge Current@10s
200A
Max. Load Power
1000W
Charge Temp.
0~+50ºC
Discharge Temp.
-20~+60ºC
Cycle Life (25ºC,0.5c,100%Dod)
2000 Time to 80% Capacity Remaining
Terminal
F12(M8)
IP Grade
IP65
Weight
26.5kg
Certificates
Un38.3/MSDS
Transport Package
Un Package
Specification
610*380*340mm
Trademark
Motekpower
Origin
China
HS Code
8507600090
Production Capacity
20000kwh/Year
Packaging & Delivery
Package Size
61.00cm * 38.00cm * 34.00cm
Package Gross Weight
26.500kg
Product Description
12V/24V/36V/48V 50ah 100ah 150ah 200ah LiFePO4 Battery
for UPS, All-in-one ESS
for UPS, All-in-one ESS
Product Parameter of 12.8V 6AH-400AH Battery
| Nominal Capacity (AH) | Rated Capacity (WH) | Nominal Voltage (V) | Max. Charging Voltage (V) | Max. Charging Current (A) | Max. Continuous Discharging Current (A) | Max. Peak Discharging Current /10S (A) | Max. Load Power (W) | Cycle Index (25ºC,0.5C, 100%DOD) | Charging Temp. (ºC) | Discharging Temp. (ºC) | Weight (KG) | Size (mm) |
| 6 | 76.8 | 12.8 | 14.6 | 6 | 10 | 20 | 100 | >2000 | 0~+50 | -20~+60 | 0.7 | 90*70*107 |
| 10 | 128 | 12.8 | 14.6 | 10 | 10 | 20 | 100 | >2000 | 0~+50 | -20~+60 | 0.9 | 151*65*100 |
| 12 | 153.6 | 12.8 | 14.6 | 12 | 20 | 40 | 200 | >2000 | 0~+50 | -20~+60 | 1.3 | 151*98*101 |
| 18 | 230.4 | 12.8 | 14.6 | 18 | 30 | 60 | 300 | >2000 | 0~+50 | -20~+60 | 1.9 | 181*77*167 |
| 20 | 256 | 12.8 | 14.6 | 20 | 30 | 60 | 300 | >2000 | 0~+50 | -20~+60 | 2.1 | 181*77*167 |
| 36 | 460.8 | 12.8 | 14.6 | 35 | 40 | 80 | 400 | >2000 | 0~+50 | -20~+60 | 4.5 | 198*166*170 |
| 50 | 460.8 | 12.8 | 14.6 | 50 | 50 | 100 | 500 | >2000 | 0~+50 | -20~+60 | 6.5 | 229*138*213 |
| 100 | 1280 | 12.8 | 14.6 | 100 | 100 | 200 | 1000 | >2000 | 0~+50 | -20~+60 | 11.8 | 328*172*215 |
| 150 | 1920 | 12.8 | 14.6 | 100 | 100 | 200 | 1000 | >2000 | 0~+50 | -20~+60 | 16.5 | 325*170*220 |
| 200 | 2560 | 12.8 | 14.6 | 100 | 100 | 200 | 1000 | >2000 | 0~+50 | -20~+60 | 26 | 522*240*218 |
| 400 | 5120 | 12.8 | 14.6 | 100 | 100 | 200 | 1000 | >2000 | 0~+50 | -20~+60 | 47 | 521*269*220 |
Product Applications
Xiamen Lynsa Intelligent Technology CO., LTD has delivered more than 1.5G WH batteries serving
100000+ users.
Xiamen Lynsa was founded in 2013 and has focused on product development in the field of batteries for 7 years. We have the expertise and integrated solution services in the power storage application industry, further catering to the needs of the smart green energy era. We always believe that energy is the driving force of the future and Xiamen Lynsa is ready to be your reliable partner to provide OEM/ODM services and complete solutions for smart power energy systems.
100000+ users.
Xiamen Lynsa was founded in 2013 and has focused on product development in the field of batteries for 7 years. We have the expertise and integrated solution services in the power storage application industry, further catering to the needs of the smart green energy era. We always believe that energy is the driving force of the future and Xiamen Lynsa is ready to be your reliable partner to provide OEM/ODM services and complete solutions for smart power energy systems.
FAQ
Q1. What other brand companies provide
Standard Products with fixed size and powers.
What Xiamen Lynsa provides
Xiamen Lynsa not only provides standard products, but also customized products on size, power, and
the output you required, is always available.
Q2. How your new products development request is handled by other brand companies
You are asked to check their brochure for any products meeting your requirement. They only work on their
standard products. And they want you to accept it as it is.
How Xiamen Lynsa will handle this
We want to first know your initial idea. And you will be invited to participate from designing to sampling, and testing
to mass production. Xiamen Lynsa is always standing firmly with you in new product development.
Q3. How do you get the products from other brand companies
There are so many distributors for the above companies. So it will not be possible for you to source from them
directly. Then you end up with their products supplied by the distributors at higher costs; Even if you got the
chance to cooperate directly, still long lead time or large MOQ orders will be expected from you.
How you get it from Xiamen Lynsa
As the factory, Xiamen Lynsa supplies products directly without any distributors, this way you get the best price to
add to your profit; Any amount of order is accepted. Xiamen Lynsa would like to grow with you together, willing to help you to develop your market, and build good relationships with your customers; we keep complete production
within the minimum lead time.
Q4. About the product quality you concern most
Xiamen Lynsa has set up an experienced QC team. Materials' guarantee is from the beginning, various testing will be done during and after production. Third-party inspections by your side are welcomed before loading for delivery.
Q5. Can I have a sample order?
A: Yes, we welcome sample orders to test and check quality.
Q6. Where can I get the price?
A: We will offer you the best quotation in 24 hours after we get the product specifications such as voltage capacity application etc.
Q7. What are your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q8. Do you test all your goods before delivery?
A: Yes, We have a professional QC team to make sure that the products are in good condition before sending out the goods.
