Basic Info.
Model NO.
TE4-0230A-L
Usage
Car Battery Charger
Interface
Clip
Color
OEM
Input Voltage
120V /230V
Output
12V
Efficient
>75%
Charging Voltage
12V
Ambient Temp
-10-40
Housing Protection
IP65
Charger
2/10/40/200 AMP
Warrenty
1 Year
Output Current
2/10/40/200 AMP
Transport Package
Color Box
Specification
Color box size:
Trademark
TONNY
Origin
China
HS Code
8504401990
Production Capacity
200000PCS
Packaging & Delivery
Package Size
36.00cm * 31.50cm * 52.50cm
Package Gross Weight
20.000kg
Product Description
6V/12V 2A/10A/40A MANUAL WHEEL BATTERY CHARGER WITH 100A/ 2 00A ENGINE START ER
Designed for charging a Truck , Boat, RV, SUV or Agricultural Machines, The TE4-0230 A-L Wheel Style Charger/Starter delivers charging current up to 4 0 A to 6 V/ 12 V lead acid batteries, features peak 2 00 amps of engine starting power to assistant emergency engine cranking . Switchable charging rate for different capacity batteries, LED indicators and Digital display showing charging current and voltage for easy operation.
Description
- For all 6V/12V lead-acid batteries(WET, MF, AGM and GEL)
- Manual wheel charger with emergency engine start function
- Switchable charging rate
- LED indication and Digital display for easy readout and operation
- Overcharge, short circuit protection
| Model | TE4-0230A-L |
| Battery Type | 6V/12V STD, GEL, AGM |
| Rated AC Input Voltage | AC105-125V, 60Hz or AC220-240V, 50Hz |
| Max Output Voltage | 14.4V±0.3V |
| Charging Current | 2A,10A,40A |
| Engine Start | 100A for 6V, 200A for 12V |
| Activated Voltage | 3V/7.5V |
| Protection | Overheat |
| Short Circuit | |
| Overcharge | |
| Housing Material | Metal |
| Color | Customized |
| Certificate | cETL /CE-EMC/CE-LVD/ROHS |
| Weight | 15.5kgs |
| Size | 30*25*42CM |
| Socket Standard | EU/AU/UK/US |
