Basic Info.
Model NO.
12V 150Ah
Discharge Rate
Low Discharge Rate
Shape
Square Battery
Electrolyte
Acid
Installation
Packaged
Rechargeable
Chargeable
Weight
44kg
Box Dimensions
499*185*299mm
Nominal Capacity
Initial Charging Current Less Than 50A Voltage 13.
Cycle Charge
Initial Charging Current Less Than 50A Voltage 14.
Self-Discharge 25ºC(77°f)
After 3 Month Storage 92%
Positive Plate
Lead Dioxide
Negative Plate
Lead
Container
ABS
Safety Valve
Si-Rubber
Terminal
Copper
Separator
Fiberglass
OEM
Acceptable
Transport Package
Carton and Pallets
Specification
484*171*241mm
Trademark
WEUP
Origin
China
HS Code
8507200000
Production Capacity
2, 000, 000PCS/Year
Product Description
1. Long battery life, high capacity, Superior of recovery after discharge.
2. ABS material: Increase the strength of battery container. (Flame-retardant ABS is optional)
3. High purity raw material: Ensure low self discharge rate.
4. Silver- coated copper terminals, brass insert terminals and lead terminals improve the electric conductivity.
5. Pb CaSn alloy for plate grids: Less gassing, less self-discharging high quality.
6. Maintenance-Free Operation
7. Low Self-Discharge
2. ABS material: Increase the strength of battery container. (Flame-retardant ABS is optional)
3. High purity raw material: Ensure low self discharge rate.
4. Silver- coated copper terminals, brass insert terminals and lead terminals improve the electric conductivity.
5. Pb CaSn alloy for plate grids: Less gassing, less self-discharging high quality.
6. Maintenance-Free Operation
7. Low Self-Discharge
| Nominal Voltage | 12V | ||||||||||||||
| Nominal Capacity (10 hour rate) | 150Ah | ||||||||||||||
| Capacity 25ºC(77°F) | 20 hour rate (8.3A) | 166Ah | |||||||||||||
| 5 hour rate (26.5A) | 132.5Ah | ||||||||||||||
| 1 hour rate (99A) | 99.0Ah | ||||||||||||||
| Internal Resistance | Full Charged Battery 25ºC | ≤4.0mΩ | |||||||||||||
| Capacity affected by Temperature (10 hour ) | 40ºC (104°F) | 102% | |||||||||||||
| 25ºC (77°F) | 100% | ||||||||||||||
| 0ºC (32°F) | 90% | ||||||||||||||
| -15ºC (5°F) | 70% | ||||||||||||||
| Self-Discharge 25ºC(77°F) Capacity | after 3 month storage | 92% | |||||||||||||
| after 6 month storage | 82% | ||||||||||||||
| after 12 month storage | 68% | ||||||||||||||
| Charge (Constant Voltage) 25ºC (77°F) | Float | Initial Charging Current Less than 30A Voltage 13.6-13.8V | |||||||||||||
| Cycle | Initial Charging Current Less than 30A Voltage 14.4-14.9V | ||||||||||||||
| Battery Dimensions | Length | 484mm | |||||||||
| Width | 171mm | ||||||||||
| Height | 241mm | ||||||||||
| Total Height | 241mm | ||||||||||
| Box Dimensions | Length | 499mm | |||||||||
| Width | 185mm | ||||||||||
| Height | 299mm | ||||||||||
| Quantity Per Box | 1 PC per box | ||||||||||
| Net weight Per Cell | 44 kg±400g | ||||||||||
| Net weight Per Box | 44kg | ||||||||||
| Gross Weight | 44.8kg | ||||||||||
