110V100A Uxcel Series Industrial Battery Charger with High Frequency Rectifier /DC UPS

Get the powerful 110V100A Uxcel Series Industrial Battery Charger with High Frequency Rectifier/DC UPS from our factory. Reliable and efficient for industrial use.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
uXcel 110V100A
Nominal Voltage
48V
Charger Style
Pulse Charger
Compatible Battery Type
Lead Acid/NiCd/ Lithium
Size
800*800*2000
Certification
RoHS, TUV, CE, Toby
Socket Type
Standard/ Flexible
Recyclable
Recyclable
Battery Type
Lead Acid Batteries, Nickle Cadmium Batteries, Lit
OEM/ODM Service
Yes, Customized Service Available
Certificates
CE, En61000, IEC60146
Nominal DC Voltage(Output)
24/48/110/125/220/240/400V
Transport Package
Cartonbox or Wooden Pallets
Specification
800*800*2000
Trademark
EverExceed
Origin
Shenzhen, China
HS Code
8504409992
Production Capacity
10000

Packaging & Delivery

Package Size
57.00cm * 60.00cm * 187.00cm
Package Gross Weight
500.000kg

Product Description


Everexceed 110V100A Uxcel Series Industrial Battery Charger with High Frequency Rectifier /DC UPS

The EverExceed uXcel range industrial battery charger is the flagship charger of EverExceed Industrial Power solutions. It integrates proven design topology with the latest advanced digital control technology to control the thyristor bridge rectifier and provides the most reliable and trouble-free performance in any electrical and industrial environments.
110V100A Uxcel Series Industrial Battery Charger with High Frequency Rectifier /DC UPS
 Key features:

110V100A Uxcel Series Industrial Battery Charger with High Frequency Rectifier /DC UPS
Large LCD display


User friendly operation with large LCD display, optional touch screen with the choices of 8 languages ensure easy maintenance and operation.Smart communication and Remote Monitoring

Leading Technology- 6 or 12 pulse controlled Thyristor technology

The embedded micro-computer controller processes signals 10 times faster than standard analog methods.
110V100A Uxcel Series Industrial Battery Charger with High Frequency Rectifier /DC UPS

110V100A Uxcel Series Industrial Battery Charger with High Frequency Rectifier /DC UPS
Isolation transformer


Filter more than 3 harmonics in the power grid interference to the system equipment, while strengthening the operation security of the system.

High Reliability and High MTBF


Precise adjustable temperature compensation, robust and unique design allows the charger to continuously operate at 40°C ambient temperature on full load. Natural ventilation and cooling are available on most of the cases.
110V100A Uxcel Series Industrial Battery Charger with High Frequency Rectifier /DC UPS



>Flexible maintenance and Reduced MTTR-The design make it easy for front-access to all vital modules modules of the charger



>Versatile constant voltage and constant current charging modes



>Smart communication and Remote Monitoring through isolated RS232, RS485, Ethernet. Full data logging


>Long design life up to 20+years-system design life up to 20+ years in continuous operation under the condition of appropriate maintenance



>Enhanced Robustness - Mechanical design to withstand vertical and horizontal acceleration stress up to 0.5g as standard
110V100A Uxcel Series Industrial Battery Charger with High Frequency Rectifier /DC UPS
110V100A Uxcel Series Industrial Battery Charger with High Frequency Rectifier /DC UPS

Recent projects:
110V100A Uxcel Series Industrial Battery Charger with High Frequency Rectifier /DC UPS


Technical specifications:


Nominal Voltage 12V 24V 48V 110V 220V 400V
Nominal Current 25-1500A 25-1500A 25-1500A 16-1500A 16-1500A 16-1000A
Input Supply                             Single phase  120V/220V/230V/240V, three phase  208V/380V/400V/415V/480V
Input Voltage/Frequency Tolerance                                                                             ± 10% , 50/60Hz ± 5%
Output Voltage                       1.8-18V            3.6-36V           7.2-72V         16.5-165V        33-330V          60-600V
Voltage Ripple                                                <2% specified full load and without battery connected.
Static Voltage Regulation      ± 1% for 0-100% load variation, ± 10% AC input voltage variation and     5% AC input frequency variation
Dynamic Voltage                                           5% for load variation of 10% to 100% or 100% to 10%
Current  Regulation                                                        ± 1%
Protection Input Circuit Breaker, Charger Output Fuse/Circuit Breaker*, Charger Current
Limit, Dual Battery Current Limit, AC Surge Suppression*, Short Circuit Protection, Reverse Battery Polarity Protection, Phase lost protection*
Alarms Charger Fail, DC High, Under/Over Voltage Trip, Earth Fault*, Low Electrolyte,Battery Disconnected*, Battery Over Temperature*, Blown Fuse*, Common Alarm Relay, Common Alarm Buzzer( All  alarms are user programmable )
Metering Charger Voltage, Charger Current, Load Voltage, Load Current, Battery Charge/Discharge Current, Battery Temperature*, Battery Capacity Ratio( Meter accuracy 1% )
Options                                        DC Voltage Regulator, TCP/IP adaptor, Triphase control and shot , Cabinet lamp, Temperature and humidity controller, DC distribution board
Physical Wall mount or free standing powder coated metal cabinet ( Dimensions depend on charger output rating and associated battery requirements  )
Environmental                                                                -10 to 50ºC, up to 95% humidity
Operating Altitude (m)                                                 3000 (with out derating)
Communication Interface                                 RS232/RS485 Modbus, TCP/IP Ethernet (optional)
DC Meter Display (Optional)           For display the voltage and current of charger on the panel
MTBF / MTTR                                              100,000 Hours / 4 Hours
Efficiency      80 to 93% depending on nominal voltage and power rating
Temperature Compensation* Programmable 3 - 6 mV / Cell / °C
Audible Noise                                                                                    <60 Db
Limp Home Feature                    Continuous operation in the event of control failure
Revert to Factory Settings                                         Reinstates all original factory settings
System                                          SCR full-bridge, Intelligence charging management, Fast acting fuse




110V100A Uxcel Series Industrial Battery Charger with High Frequency Rectifier /DC UPS 110V100A Uxcel Series Industrial Battery Charger with High Frequency Rectifier /DC UPS
110V100A Uxcel Series Industrial Battery Charger with High Frequency Rectifier /DC UPS
FAQ:
Q 1 : Are your factory or trading company?
A: We are professional battery manufacturer with our own factory and brand. We provide all kinds of OEM/ODM services for clients,  can produce by your samples or technical drawings. We can build the molds and fixtures.

Q2.Can I have a sample order?
A:  Yes, we welcome sample order to test and check quality.

Q3:  Where can I get the price?
A: We will offer you the best quotation in 12 hours after we get the product specifications such as voltage capacity application etc.

Q 4 . What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.

Q 5 . How about your delivery time?
A:Generally,  it will take 15-30 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.

Q 6 . Do you test all your goods before delivery?
A: Yes, We have professional QC team to make sure that the product in good condition before send out the goods.

Q 7 : How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
   2. We respect every customer as our friend and we sincerely do business and make friends with them,  no matter where they come from.
