Basic Info.
Model NO.
ASLB-48-LIFEPO4
Rated Capacity
>1000MAH
Standard Voltage
>12V
Usage
Remote Control Boat, Remote Control Plane, Remote Control Car
Electrolyte
Li-ion
Weight
24kg; 32kg
Voltage
48V
Transport Package
Carton/Wooden Box
Specification
442*410*89mm
Trademark
Pylontech
Origin
Jiangsu, China
Production Capacity
20000pieces/Month
Product Description
| Basic Parameters | US2000 | US3000 |
| Nominal Voltage (V) | 48 | 48 |
| Nominal Capacity (Wh) | 2400 | 3552 |
| Usable Capacity (Wh) | 2200 | 3200 |
| Dimension (mm) | 442*410*89 | 442*420*132 |
| Weight (Kg) | 24 | 32 |
| Discharge Voltage (V) | 45 ~ 53.5 | 45 ~ 53.5 |
| Charge Voltage (V) | 52.5 ~ 53.5 | 52.5 ~ 53.5 |
| Charge/ Discharge Current (A) | 25 (Recommended) | 37 (Recommended) |
| 50 (Max) | 74 (Max) | |
| 100 (Peak@15s) | 100 (Peak@15s) | |
| Communication Port | RS485, CAN | RS485, CAN |
| Single string quantity (pcs) | 8 | 8 |
| Working Temperature/ºC | 0 ~ 50 | 0 ~ 50 |
| Shelf Temperature/ºC | -20 ~ 60 | -20 ~ 60 |
| Humidity | 5% ~ 85% | 5% ~ 85% |
| Altitude (m) | <2000 | <2000 |
| Design life | 10+ Years (25ºC/77ºF) | 10+ Years (25ºC/77ºF) |
| Cycle Life | >6000, 25ºC | >6000, 25ºC |
| Authentication Level | UL/TÜV/CE /UN38.3 | UL/TÜV/CE /UN38.3 |
