Basic Info.
Model NO.
Fast EV Charging Station
Charge Method
Quick Charge
Application
for EV Fast Charging Station
EV Plug
Chademo CCS and GB/T
Communication
Ocpp
Charger Speed
DC Fast
Cooling Unit
Fans Cooling
LCD Screen
4.3inch LCD Screen
Authorization Way
RFID Billing System
After-Sales Service
2 Year Warranty
Type
Fast EV Charging Station
Certification
CE
Warranty
24 Months
Transport Package
Wooden
Specification
645 * 454 * 170mm
Trademark
NASN
Origin
China
HS Code
8504409992
Production Capacity
1000/Month
Packaging & Delivery
Package Size
64.00cm * 45.00cm * 17.00cm
Package Gross Weight
35.000kg
Product Description
Wall mounted EV Charger
30KW Wallbox DC Fast Charger is meant to quickly and simply charge electric vehicles, including the one equipped with high-voltage battery systems. The portable DC fast charger series' performance makes it very suitable for personal and little fleets. Modern design, friendly UI and multi standard compatible, this DC fast unit can support plug hot-swapping technology, to satisfy the charging needs of vehicles with different standards.
Features:
√ Wall mounted Charger -widely usage senario indoor and outdoor. Packing Lot, Gas Station, Highway Station, hotel and so on.
√ Multi Standard - With plug and play type ev connector, to meet all possible electric vehicles. CHAdeMo, CCS Combo 1, CCS Combo 2 and GB/T for your option. DC output cable can be customized based on request.
√ DC Fast Charge Speed -Fast charger provide great convenience for modern people's fast-paced life. People can fill up electric cars in a short time while drinking coffee and shopping.
√ Rated output power - This portable charger with input voltage of 380V, voice navigation, easy to use, rated output power. 30KW and 60KW for your option.
Applications:
For personal use, home use, for ev fleet, ev bus, electric heavy truck, light vehicle and charger sharing,
Datasheet:
Other Popular
SOLAR EV CHARGING STATION
GRID FREE EV BATTERY STORAGE CHAGER SYSTEM
PORTABLE EV CHARGER
HIGH POWER PUBLIC COMMERCIAL EV Charger
Factory Details
FAQ
Q1.What's the difference between Movable Charger and Wallbox Charger?
A: wallbox charger protection level is IP54, available outdoors with RFID billling system
And the Movable Charger protection level is IP43, rainy days and other weather can not be used outdoors.
Q2.What is the warranty?
A: 12 months. In this period, we will supply technical support and replace the new parts by free,customers are in charge of delivery.
Q3. What is your terms of packing?
A: Generally, we pack our goods in brown cartons. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.
Q4. What is your terms of payment?
A: T/T 50% as deposit, and 50% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q5. What is your terms of trade?
A: EXW, FOB, CFR, CIF, DAP,DDU,DDP
Q6. How about your delivery time?
A: Generally, it will take 3 to 7 working days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q7. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q8. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.
Q9. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery.
30KW Wallbox DC Fast Charger is meant to quickly and simply charge electric vehicles, including the one equipped with high-voltage battery systems. The portable DC fast charger series' performance makes it very suitable for personal and little fleets. Modern design, friendly UI and multi standard compatible, this DC fast unit can support plug hot-swapping technology, to satisfy the charging needs of vehicles with different standards.
Features:
√ Wall mounted Charger -widely usage senario indoor and outdoor. Packing Lot, Gas Station, Highway Station, hotel and so on.
√ Multi Standard - With plug and play type ev connector, to meet all possible electric vehicles. CHAdeMo, CCS Combo 1, CCS Combo 2 and GB/T for your option. DC output cable can be customized based on request.
√ DC Fast Charge Speed -Fast charger provide great convenience for modern people's fast-paced life. People can fill up electric cars in a short time while drinking coffee and shopping.
√ Rated output power - This portable charger with input voltage of 380V, voice navigation, easy to use, rated output power. 30KW and 60KW for your option.
Applications:
For personal use, home use, for ev fleet, ev bus, electric heavy truck, light vehicle and charger sharing,
Datasheet:
| product model | NI-07750 | NI-15750 | NI-20750 | NI-30750 |
| output power | 7KW | 15KW | 20KW | 30KW |
| The AC input voltage range | 90-265V | 265-475V | 265-475V | 265-475V |
| input current | 32A | 30A | 40A | 50A |
| Output voltage range | 200-750V | |||
| display mode | 4.3-inch color touch screen | |||
| frequency domain | 45-66HZ | |||
| Product efficiency | ≥95% | |||
| Output current | 20A | 25A/37.5A | 33A/60A | 50A/100A |
| auxiliary source | Default 12V (optional 24V) | |||
| size | 545*380*170mm | 645*454*170mm | ||
| Net weight | 20KG | 30KG | 35KG | 45KG |
| Charger gun length | 5M (accept customize) | |||
| Altitude | 2000M | |||
| working temperature | -20ºC-50ºC | |||
| storage temperature | -40ºC-70ºC | |||
| Protect | Lightning protection, overload, short circuit over temperature, electricity leakage, emergency stop protection, etc | |||
| function | ||||
| Charging selection | Plug and play, timing, reservation, payment, etc | |||
| mode of payment | RFID card, (option scan code ,credit card,QR CODE,APP) | |||
| Network Connection | Optional (4G module / wifi / Ethernet) | |||
| levels of protection | IP54 | |||
| Optional function | OCPP | |||
Other Popular
Media Charging Station with 49inch 55inch Adversting Screen
LOW VOLTAGE 40-100Vdc EV CHARGERSOLAR EV CHARGING STATION
GRID FREE EV BATTERY STORAGE CHAGER SYSTEM
PORTABLE EV CHARGER
HIGH POWER PUBLIC COMMERCIAL EV Charger
Factory Details
GUANGZHOU NASN POWER CO.,LTD is dedicated to producing and manufacturing AC EV charger, DC EV charger, DC power supply and battery storage products. As a professional manufacturer, NASN POWER focuses on providing customers with professional charging equipment that is safer, more efficient and more stable. NASN's products are oriented to the household and commercial markets in the EV and power supply charging field, including all kinds of EV Connector and EV Charger Sockets, EV Charging Cables, emergency rescue EV charger system, V2H and V2V charger, Solar EV charger system,Media screen EV charger, Portable DC fast EV Charger, Public multi-standards DC fast charger, e-scooter and e-motorcycle charger, Portable POWER STATION,portable battery speaker, and DC power supply.
Q1.What's the difference between Movable Charger and Wallbox Charger?
A: wallbox charger protection level is IP54, available outdoors with RFID billling system
And the Movable Charger protection level is IP43, rainy days and other weather can not be used outdoors.
Q2.What is the warranty?
A: 12 months. In this period, we will supply technical support and replace the new parts by free,customers are in charge of delivery.
Q3. What is your terms of packing?
A: Generally, we pack our goods in brown cartons. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.
Q4. What is your terms of payment?
A: T/T 50% as deposit, and 50% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q5. What is your terms of trade?
A: EXW, FOB, CFR, CIF, DAP,DDU,DDP
Q6. How about your delivery time?
A: Generally, it will take 3 to 7 working days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q7. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q8. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.
Q9. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery.
