Basic Info.
Model NO.
SCDE100-80-240-DC
Efficiency
94% (Full Load)
Maximum Input Current
155A
Charging Interface
CCS 2* or GB
Internet Connection
4G /Ethernet
Input Power Connection
3pH+N+PE(L1, L2, L3, N, PE)
Transport Package
Cardboard Box
Specification
700*1900*600mm
Trademark
SOJO or OEM
Origin
China Anhui
Production Capacity
10000
Product Description
Company Profile:
Product rule parameters:
Storage and transportation of equipment:
There should be corresponding fastening measures during transportation to avoid strong vibration and bumps damaging the outer packaging of the equipment. Upon arrival, you should check whether there is any damage, if there is any transportation damage, you should negotiate with the transportation party and our company to solve the problem. After opening the box, you should immediately check whether the contents of the box are consistent with the packing list.
Packed equipment should be stored in a room with relative humidity ≤80% and ambient air temperature -10ºC~+40ºC. The storage place should be dry, clean, air circulation, and can prevent the intrusion of all kinds of harmful gases, it is strictly prohibited to store with corrosive substances in the same place.
Our factory:
FAQ
Q1.Are you a factory or trading company?
A: We are a professional manufacturer of new and sustainable energy applications .
Q2.What is the warranty?
A: 12 months. In this period, we will supply technical support and replace the new parts by free, customers are in charge of delivery.
Q3. What is your terms of payment?
A: T/T 50% as deposit, and 50% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q4. What is your terms of trade?
A: EXW, FOB, CFR, CIF, DAP,DDU,DDP
Q5. How about your delivery time?
A: Generally, it will take 3 to 7 working days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q6. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q7. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.
Q8. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery.
SOJO Electric Co., Ltd.,
1,Leading enterprises of power distribution industry in China
2,Wins"national Torch Program industrialization demonstration project certificate
3,The only enterprise pass KEMA certificate in China
Listed on Shenzhen Stock Exchange in April 2015.(Stock Code:300444)
4,Possess multiple international invention patents
5,Specializes in the R & D, production, sales and operation in new energy field
6,Owning a 350,000 m2 digital factory in middle of China
7,Set up in 2002 have rich experience in production
8,Annual output value over 5 billion RMB
9,Global Employees more than 2000 people
1) The column type AC charging pile can be installed in outdoor operation, but the top of the equipment should be equipped with a canopy to prevent rainwater from directly drenching the equipment;
2) According to the installation position shown on the left, drill the expansion bolt installation holes, install the expansion bolts and waterproof rubber gasket in sequence, fix the AC pile on the column, install the waterproof rubber gasket on the top of the internal expansion bolts, fix it with nuts and then fix it with sealant;
3) Fix the gun line hook holder with screws on the center fixing hole of the column;
4) Ground the body reliably to avoid electric shock causing casualties;
5) The pile is usually made 20 centimeters high foundation, and the column is fixed on the foundation with expansion bolts.
2) According to the installation position shown on the left, drill the expansion bolt installation holes, install the expansion bolts and waterproof rubber gasket in sequence, fix the AC pile on the column, install the waterproof rubber gasket on the top of the internal expansion bolts, fix it with nuts and then fix it with sealant;
3) Fix the gun line hook holder with screws on the center fixing hole of the column;
4) Ground the body reliably to avoid electric shock causing casualties;
5) The pile is usually made 20 centimeters high foundation, and the column is fixed on the foundation with expansion bolts.
| Name | Parameters |
| Rated power | 60-240kw |
| Body size (H*W*D) | 700*1900*600mm |
| Input power connection | 3Ph + N + PE(L1, L2, L3, N, PE) |
| Certification | CE |
| AC input voltage | 400 VAC ± 10% |
| Operating temperature | -20+50ºC |
| Ambient humidity | 5%~95% No condensation |
| Maximum Output Current | 155A |
| Length of charging guns | Nominal 5 meters |
| Number of charging guns | single gun/double guns |
| Protection class | IP54 |
| Input power connection | 3Ph + N + PE(L1, L2, L3, N, PE) |
| AC input frequency | 50/60Hz |
| HMI | 7 inch LCD touch screen |
| Storage Temperature | -20ºC~50ºC |
| RFID system | ISO 14443 type A MIFARE DESFire EV1 |
| Communication Protocol | OCPP 1.6 |
| Energy meter | EU MID Approved Energy meter |
| Safety standards | IEC 61851 or GB |
| Internet connection | 4G/Ethernet |
| Module Configuration | Triple Harmonization Module |
Project case&Certificate:
Customer Service:
We can provide customers with professional product advice and purchase options.
All emails will be responded with in 24 hours during working days.
We have online customer service in English, Japanese. You can communicate with ease, or contact us through email anytime.
All customers will get one-on-one service.
Storage and transportation of equipment:
There should be corresponding fastening measures during transportation to avoid strong vibration and bumps damaging the outer packaging of the equipment. Upon arrival, you should check whether there is any damage, if there is any transportation damage, you should negotiate with the transportation party and our company to solve the problem. After opening the box, you should immediately check whether the contents of the box are consistent with the packing list.
Packed equipment should be stored in a room with relative humidity ≤80% and ambient air temperature -10ºC~+40ºC. The storage place should be dry, clean, air circulation, and can prevent the intrusion of all kinds of harmful gases, it is strictly prohibited to store with corrosive substances in the same place.
Our factory:
FAQ
Q1.Are you a factory or trading company?
A: We are a professional manufacturer of new and sustainable energy applications .
Q2.What is the warranty?
A: 12 months. In this period, we will supply technical support and replace the new parts by free, customers are in charge of delivery.
Q3. What is your terms of payment?
A: T/T 50% as deposit, and 50% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q4. What is your terms of trade?
A: EXW, FOB, CFR, CIF, DAP,DDU,DDP
Q5. How about your delivery time?
A: Generally, it will take 3 to 7 working days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q6. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q7. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.
Q8. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery.
