Basic Info.
Model NO.
RB48V100AH
Installation
Rack Mount
Application
Base Station, Home Energy Storage Battery, UPS
OEM/ODM
Acceptable
Charge Temperature
0 ~45 Degree Centigrade
Case
Metal
Transport Package
Un Carton
Specification
3U/4U/5u/6u
Trademark
EVERBEST
Origin
China
HS Code
8507600090
Production Capacity
50000/PCS Per Month
Product Description
Rechargeable Lithium Battery Pack 48V 100ah 150ah 200ah 400ah 500ah Li-ion/ Lithium Ion LiFePO4 Battery for UPS home solar Energy Storage System powerwall
>> Excellent charge and discharge capacity.
>> The Batteries can support up to 15 batteries in parallel for expansion.
>> The Batteries are set to sleep mode (off) during transportation and storage to reduce loss of capacity.
>> Disconnect active power from output terminals for enhanced safety.
>> Lightweight and compact.
>> Easy to install and maintain.
>> Built-in Battery Management System (BMS).
>> Environmentally friendly.
>> Rentech provides Lithium-ion batteries with proven Lithium Iron Phosphate (LifePO4) chemical composition.
>> This product has a 3-5-year warranty
3U/4U/5U ARE AVAILABLE
Q1. Can I have a sample order?
A. Yes, we welcome sample order to test and check quality.
Q2. What about the lead time?
A. Sample needs 5-10 days, mass production time needs 3-5 weeks, it depends on order quantity.
Q3. Do you have any MOQ limit?
A. Yes, we have MOQ for mass production, it depends on the different part numbers. 1~10pcs sample order is available. Low MOQ, 1pc for sample checking is available.
Q4. How do you ship the goods and how long does it take to arrive?
A. We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping is also optional.
Q5. How to proceed with an order?
A. Firstly let us know your requirements or application. Secondly, We quote according to your requirements or our suggestions.Thirdly customer confirms the samples and places a deposit for formal order. Fourthly We arrange the production.
Q6. Is it OK to print my logo on the product?
A. Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
This Lithium-Ion Battery has a long lifespan of 6 000 cycles at 80% depth of discharge at 25°C. In addition, the batteries can support up to 15 batteries in parallel for expansion. The batteries are set to sleep mode (off) during transportation and storage to reduce loss of capacity. has the following remarkable characteristics:
>> Long lifespan of 6000 cycles at 80% DoD at 25'C.>> Excellent charge and discharge capacity.
>> The Batteries can support up to 15 batteries in parallel for expansion.
>> The Batteries are set to sleep mode (off) during transportation and storage to reduce loss of capacity.
>> Disconnect active power from output terminals for enhanced safety.
>> Lightweight and compact.
>> Easy to install and maintain.
>> Built-in Battery Management System (BMS).
>> Environmentally friendly.
>> Rentech provides Lithium-ion batteries with proven Lithium Iron Phosphate (LifePO4) chemical composition.
>> This product has a 3-5-year warranty
| Model | RM48100-4U |
| Nominal voltage | 51.2V(16S), we also have 48V with 15S |
| Nominal capacity | 100Ah |
| Size | 430*442*177mm (3U/4U or other customized size are available) |
| Weight | 48KG |
| Charging method | CC/CP/VP |
| Charging current | 0.2C (Standard)/1C(Maximum continuous charging current) |
| Charging cut-off voltage | 58.4V/CELL |
| Discharge method | CC/CP/VP |
| Discharge current | 0.5C (Standard)/1.5CMaximum continuous discharge current |
| Discharge cut-off voltage | 43.2V/CELL |
| Display | LCD |
| Communication Interface | 485/232/can |
| Operating temperature | Charge:0~+50ºC/Discharge: -20~+55ºC |
| Storage temperature | Short-term storage:-10~+45 ºC(<3 month, SOC: 20%~60%)/long-term stroage:-10 ~+40 ºC(<1 year, SOC: 30%~60 %) |
| Storage humidity | 5%~95% |
| Shipping status | Voltage: 48~51V/SOC:30%~50% |
3U/4U/5U ARE AVAILABLE
Q1. Can I have a sample order? A. Yes, we welcome sample order to test and check quality.
Q2. What about the lead time?
A. Sample needs 5-10 days, mass production time needs 3-5 weeks, it depends on order quantity.
Q3. Do you have any MOQ limit?
A. Yes, we have MOQ for mass production, it depends on the different part numbers. 1~10pcs sample order is available. Low MOQ, 1pc for sample checking is available.
Q4. How do you ship the goods and how long does it take to arrive?
A. We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping is also optional.
Q5. How to proceed with an order?
A. Firstly let us know your requirements or application. Secondly, We quote according to your requirements or our suggestions.Thirdly customer confirms the samples and places a deposit for formal order. Fourthly We arrange the production.
Q6. Is it OK to print my logo on the product?
A. Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
