Basic Info.
Model NO.
MP1218
Size
Small
Weight
2.0kg
Nominal Voltage
12.8V
Operating Temperature
Charging: 0ºC~45ºC
Typical Capacity
18.0ah
Quick Charge Current
9A (0.5c5rate)
Quick Discharge Current
18A (1.0c5rate)
Charging Voltage
14.4V±0.02V
Over Charging Protect
3.65V±0.025V
Standard Charging Current
3.6A (0.2c)
Max. Charging Current
18A
Cut-off Charging Current
0.36A (0.02c)
Standard Discharging Current
3.6A (0.2c)
Max. Discharging Current
18A
Discharging Cut-off Voltage
10V
Over Discharging Protect
2.5±0.08V
Transport Package
Wooden Package
Specification
151mm*99mm*99mm
Trademark
MD
Origin
Kaifeng
HS Code
8507600090
Production Capacity
200, 000 Pieces/Year
Packaging & Delivery
Package Size
151.00cm * 99.00cm * 99.00cm
Package Gross Weight
2.000kg
Product Description
tems | Parameter |
Charging Method | CC-CV |
Charging Voltage | 14.4V±0.02V |
Over Charging Protect | 3.65V±0.025V |
Standard Charging Current | 3.6A (0.2C) |
Max. Charging Current | 18A |
Cut-off Charging Current | 0.36A (0.02C) |
Standard Discharging Current | 3.6A (0.2C) |
Max. Discharging Current | 18A |
Discharging cut-off Voltage | 10V |
Over Discharging Protect | 2.5±0.08V |
Over Charge Current | 55±5A |
Over Discharge Current | 55±5A |
Internal Resistance | <150mOhm |
balancing voltage | 3.50±0.05V |
balancing current | 36±5mA |
Standard Charge Temperature | 0~45ºC |
Standard Discharge Temperature | -20~60ºC |
Storage Humidity | 65%RH not condensed |
Storage Temperature | -20~60ºC |
Weight | 2kg |
