Basic Info.
Model NO.
AG-E7T2316
Customization
Yes
Technical Exchange
Face to Face
Service
OEM & ODM
Project
Pre-Evaluation with Client
Delivery
Fast and Efficiency
After-Sales Service
24/7
Type
Fast EV Charging Station
Certification
CCC, CE, TUV, RoHS
Warranty
24 Months
Transport Package
by Sea, by Air
Specification
390x230x130mm
Trademark
OEM
Origin
Shanghai
HS Code
8504409999
Production Capacity
3000sets/Month
Product Description
22Kw Commercial Version
Competitive Key Advantages
No earth rod required
PME PEN loss protection
Working TNCS and TT system
Default Off -peak charging available
Random delay monitoring available
Demand Side Respond Service available
Anti-tamper available
E-Switch function for economy tariff
Total power monitoring
Dynamic load balance monitoring
Solar power/Battery monitoring available
Wifi & Ethernet & Blue tooth connectivity
Welded contacts detection
RS485 Adaptor wired to CT
3x RFID cards + App monitoring as standard
Built in independent MID meter
Auto Test
Home-use available for Commercial use
Reset Button
3 Year Warranty
Optional Choice
5m Tethered Version
1st wired CT with 5m Cat5 cable for home load balance
2ed wired CT with 5m Cat5 cable for solar circuit
3rd wired CT with 5m cat5 cable for battery circuit
Home use working as commercial function
Competitive Key Advantages
No earth rod required
PME PEN loss protection
Working TNCS and TT system
Default Off -peak charging available
Random delay monitoring available
Demand Side Respond Service available
Anti-tamper available
E-Switch function for economy tariff
Total power monitoring
Dynamic load balance monitoring
Solar power/Battery monitoring available
Wifi & Ethernet & Blue tooth connectivity
Welded contacts detection
RS485 Adaptor wired to CT
3x RFID cards + App monitoring as standard
Built in independent MID meter
Auto Test
Home-use available for Commercial use
Reset Button
3 Year Warranty
Optional Choice
5m Tethered Version
1st wired CT with 5m Cat5 cable for home load balance
2ed wired CT with 5m Cat5 cable for solar circuit
3rd wired CT with 5m cat5 cable for battery circuit
Home use working as commercial function
![7kw AC Solar Powered Electric Vehicle Charging Stations IEC 62196-2 with Floor-Mounted Level 2 Type 2 Solar Powered Car Solar Power Battery Car Charger](http://img6.grofrom.com/www.dechichargersupply.com/226f3j00mqeiDyGUbQgC/7kw-AC-Solar-Powered-Electric-Vehicle-Charging-Stations-IEC-62196-2-with-Floor-Mounted-Level-2-Type-2-Solar-Powered-Car-Solar-Power-Battery-Car-Charger.webp)
![7kw AC Solar Powered Electric Vehicle Charging Stations IEC 62196-2 with Floor-Mounted Level 2 Type 2 Solar Powered Car Solar Power Battery Car Charger](http://img6.grofrom.com/www.dechichargersupply.com/226f3j00TqeWLQUFvEgS/7kw-AC-Solar-Powered-Electric-Vehicle-Charging-Stations-IEC-62196-2-with-Floor-Mounted-Level-2-Type-2-Solar-Powered-Car-Solar-Power-Battery-Car-Charger.webp)
![7kw AC Solar Powered Electric Vehicle Charging Stations IEC 62196-2 with Floor-Mounted Level 2 Type 2 Solar Powered Car Solar Power Battery Car Charger](http://img6.grofrom.com/www.dechichargersupply.com/226f3j00abeWIuUcqtpK/7kw-AC-Solar-Powered-Electric-Vehicle-Charging-Stations-IEC-62196-2-with-Floor-Mounted-Level-2-Type-2-Solar-Powered-Car-Solar-Power-Battery-Car-Charger.webp)
Performance | |
Housing case | Plastic/Steel |
Mounting Location | Outdoor /Indoor (permanent mounting) |
Charging Model | Model 3(IEC61851-1) |
Charging Interface Type | IEC62196-2 Type 2 socket, Tethered optional |
Charging current | 63A |
Display | RGB Led indicator as standard |
Operation | App monitoring +RFID cards as standard |
IP Grade | IP65 |
Operation Temperature | -30°C ~ +55°C |
Operation Humidity | 5% ~ 95% without condensation |
Operation Attitude | <2000m |
Cooling method | Natural air cooling |
Enclosure Dimensions | 390x230x130mm |
Weight | 10KG |
Electrical Specifications | |
Input Voltage | 380Vac±10% |
Input Frequency | 50Hz |
Output Power | 11KW |
Output Voltage | 380Vac |
Output Current | 63A |
Standby power consumption | 3w |
Earth leakage protection (Type A+6mA DC) | √ |
Type A RCMU on PE wire | √ |
PEN protection as standard | √ |
No earth rod required as standard | √ |
