Basic Info.
Model NO.
FN300
Nominal Voltage
12V/24V
Charger Style
Intelligent Charger
Compatible Battery Type
12-Volt
Size
Automotive Lead Acid Battery
Certification
RoHS, CE
Socket Type
For E.U.
Recyclable
Recyclable
Specification
137*90*51mm
Trademark
FUNELEC
Origin
China
Production Capacity
100000/Month
Packaging & Delivery
Package Size
13.70cm * 9.00cm * 5.10cm
Package Gross Weight
1.000kg
Lead Time
7 days (1 - 300 Pieces)
To be negotiated ( > 300 Pieces)
To be negotiated ( > 300 Pieces)
Product Description
Input voltage : 100VAC~ 240VAC 50HZ/60HZ | CV | CC | Transition / Cut-off Current | Net Weight | Size | Package | |||||
Item No. | Input voltage | Lead Acid | Li-ion | LiFePO4 | 110V | 220V | Lead Acid (A) | Li(A) | (kg) | (mm) | ( pcs/ctn ) |
F300 | 12V | 14.5V | 12.6/16.8V | 14.6V | 15A | 15A | 3 | 1.5 | 1 | 137*90*51 | 12pcs/ctn |
24V | 29V | 25.2/29.4 /33.6V | 29.2V | 9A | 10A | 1.8/2A | 0.9/1A | ||||
36V | 43.5V | 42.0V | 43.8V | 6A | 6.5A | 1.2/1.3A | 0.6/0.65A | ||||
48V | 58V | 50.4/54.6/ 58.8V | 58.4V | 4.5A | 5A | 0.9/1A | 0.45/0.5A | ||||
60V | 72.5V | 63/67.2/ 71.4V | 73V | 3.5A | 4A | 0.7/0.8A | 0.35/0.4A | ||||
72V | 87V | 84/88.2V | 87.6V | 3A | 3.5A | 0.6/0.7A | 0.3/0.35A |
Efficiency | 90% | Leakage Current | <=0.75mA |
Operating Humidity | 5%-95% RH Non-condensing | Altitude | 2000m |
Operating Temperature | -20ºC-+40ºC | Storage Temperature | -40ºC-+80ºC |
Safety Certifications | CE, RoHS | ||
Suitable battery Type | Lead Acid/LiFePo4/Li-ion and so on | ||
Charging Time | Transition for Li battery is 10% of CC, and it can be setted between 5-10%. (charging time:3-4 hours) | ||
Transition for Lead Acid battery is 20% of CC, and it can be setted between 15-30%.(charging time:6-8 hours) | |||
Protection | Over Current, Over Voltage, Over temperature, Short Circuit, Reverse Polarity | ||
Advantage | |||
Can add a switch for 110/220Vac | |||
Cooling by built-in silent DC fan | |||
Aluminum case, Robust, Elegant and Reliable | |||
Low surge current,LLC resonance soft-switching technology,sychronous rectification; no interference,low output voltage ripple | |||
Package Contents | *1xbattery charger *1xInput Wire *1xOutput Fuse *1xUser Manual |
