Basic Info.
Packaging & Delivery
10 days (2 - 10 Pieces)
50 days (11 - 50 Pieces)
To be negotiated ( > 50 Pieces)
Product Description
Model | XTM 1500-12 | XTM 2000-12 | XTM 2400-24 | XTM 3500-24 | XTM 2600-48 | XTM 4000-48 | |
| Characterisation of the operating performance | |||||||
| Nominal battery voltage | 12V | 12V | 24V | 24V | 48V | 48V | |
| Input voltage range | 9.5-17VDC | 9.5-17VDC | 19-34VDC | 19-34VDC | 36-68VDC | 36-68VDC | |
| Continuous Power | 1500VA | 2000VA | 2000VA | 3000VA | 2000VA | 3500VA | |
| Power 30 min. | 1500VA | 2000VA | 2400VA | 3500VA | 2600VA | 4000VA | |
| Power 5 Sec. | 3400VA | 4800VA | 6000VA | 9000VA | 6500VA | 10500VA | |
| Max.efficiency | 93% | 93% | 94% | 94% | 96% | 96% | |
| Own consumption stand by | 1.4W | 1.4W | 1.6W | 1.6W | 2.0W | 2.1W | |
| Own consumption stand by | 8.0W | 10W | 9W | 12W | 10W | 14W | |
| Acoustic level without ventilation | 40 dB | ||||||
| Acoustic level with ventilation | 45 dB | ||||||
| Maximum load | Up to short-circuit | ||||||
| Maximum asymmetric load | Up to Pcont. | ||||||
| Load detection (stand-by) | 2 to 25 W | ||||||
| Cos φ | 0.1-1 | ||||||
| Output voltage | Pure sine wave 230Vac (±2%) / 120Vac (1) | ||||||
| Output frequency | 45Hz-60Hz(1) ± 0.05% (crystal controlled) | ||||||
| Harmonic distortion | <2% | ||||||
| Overload and short-circuit protection | Automatic disconnection with 3 time restart attempt | ||||||
| Overheat protection | Warning before shut-off - with automatic restart | ||||||
| Battery charger | |||||||
| Charge Characteristic | 6 steps : Bulk-Absorption-Floating-Equalization-reduced floating-periodic absorption Number of steps,thresholds,end current and times completely adjustable with the RCC-02/03 | ||||||
| Temperature compensation | With BTS-01 or BSP 500/1200 | ||||||
| Maximum charging current | 70A | 100A | 55A | 90A | 30A | 50A | |
| Input voltage range | 150 to 265Vac / 50 to 140Vac (1) | ||||||
| Input frequency | 45 to 65Hz | ||||||
| Input current max . (transfer relay) / Output current max . | 50Aac / 56Aac | ||||||
| Transfer time | < 15ms | ||||||
| Protection index | IP 20 | ||||||
| Operating temperature range | -20 to 55ºC | ||||||
| Ventilation | Forced from 55ºC | ||||||
| Warranty | 2 Years | ||||||
Q1. What's Certificates you have?
A: CE, ROHS, ISO9001, SGS certificates
Q2. How many years warranty?
A: All of products warranty 2 years. If have any quality problem, could return to us exchange new one or repair it free. Use our company DHL account, free freight.
Q3. What's the payment term?
A: 100% T/T (large order, accept 30% T/T prepay 70% balance before shipping), Western Union, Paypal.
Q4. How's the delivery time?
A: Usually 2 hours after receive full payment. OEM order need 10-15 days.
Q6. Why choose Fangpusun pure sine wave inverter?
A: . Fangpusun inverter, its wave better than electric supply, used for military, car, boat, solar home system. Does not affect radio transmission.
. Through testing, Fangpusun inverter is full power. Many other supplier only 70% or 80% power.
Q7. What's Government tender you get?
A: FP-S-300W and FP-S-600 inverter get Indonesia tender, Solarix MPPT2010 controller get Bulgaria tender, PR2020 solar controller get Ecuador tender, PR3030 solar charge controller get Mexico tender and so on.
Q8. Would you supply OEM/ ODM service?
A: Yes! Our company supply OEM service.
. MOQ 200Pcs per model, blank box packing, standard export carton.
. MOQ 500Pcs per model, customer's design color box packing, standard export carton.
Q9. Why your unit price is higher than other supplier?
A: Alto and Audi are cars, also four wheels cars. Why Audi price higher than Alto? The same token, our Fangpusun power inverter unit price higher than other supplier, so products quality higher than other supplier. We believe in the right balance between quality and price. We offer competitively priced systems while maintaining our high standard of quality.
Q10. Engineering expertise
A: In Fangpusun we know that every project is different. Our solar experts with 10 year experience, will conduct a solar site analysis using the latest tools in the industry to ensure the maximum performance of your solar system. Give you the best suggestion, recommend suitable model for you.
Q11. What about your sale service?
A: Developing long-lasting relations with our customers is of utmost importance to us. We are committed to providing you with excellent all-round services, before, during and after the installation of your renewable energy syste.
