Basic Info.
Product Description
Features
1 | Design meeting RoHS / CE |
2 | High efficiency: 93% |
3 | Non-isolated between input and output |
4 | Internal capacitor: NCC & NICHICON (high reliability) |
5 | 100% full load burn-in test |
6 | Over temperature, Over load and Over voltage protections |
7 | Waterproof level IP67 |
8 | 12 months warranty |
Technical Parameter
Brand | IDEALPLUSING |
Type | Non-isolated |
Model | IPS-DTDC10-36S13.82 |
DC voltage INPUT | |
Voltage rate | 10~36VDC |
Voltage range | 10~36VDC |
DC voltage & Current output | |
Voltage rate | 13.8VDC |
Current | 2A |
Rate Power | 27.6W |
Type of rechargeable battery | 12V storage battery(AGM) |
Size | 74*74*32(MM) |
NW | 300G |
Others | |
Customize | Allow |
Material of shell | Aluminum shell |
Working temp | -20~80ºC |
Efficiency | 93% |
Waterproof Level | IP67 |
Note: All specifications are subject to charge or change without prior notice. | |
Q1. Can I have a sample order?
A: Yes, sample order is acceptable to test and check quality for the first cooperation
Q2. What about the lead time?
A: Most of the model in the stock, sample lead time after receive payment 1-3 working days
Q3. Do you have any MOQ limit?
A: Low MOQ, 5 pieces for sample checking is available.
Q4. How do you ship the goods and how long does it take to arrive?
A: We often ship by DHL, UPS, FedEx, or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping is also optional.
Q5. How to proceed with an order?
A: Initially, let us know your requirements or application. Besides, We quote according to your requirements or our suggestions. Thirdly, customers confirm the samples and places deposit for formal order. Finally, We arrange production.
Q6. Is it acceptable to print the buyer logo on the product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7: How to deal with the flaw?
A: Our products are produced in a strict quality control system and the percent of pass is often maintained over 99.8%.
Q8: Do you offer a guarantee for the products?
A: Yes, we offer a 1-year warranty for all power supply.
BACK TO HOME or CANTACT US
| Charging DC DC converter | ||||
| NO. | Model | Specifications | Note | Size(MM) |
| #1 | IPS-DTDC8-36S12.610 | 8~36VDC to 12.6VDC 10A | It can charge 12V lithium battery | 74*74*32 |
| #2 | IPS-DTDC8-36S12.620 | 8~36VDC to 12.6VDC 20A | It can charge 12V lithium battery | 100*80*39 |
| #3 | IPS-DTDC8-36S13.88 | 8~36VDC to 13.8VDC 8A | It can charge the 12V storage battery | 74*74*32 |
| #4 | IPS-DTDC8-36S13.820 | 8~36VDC to 13.8VDC 20A | It can charge the 12V storage battery | 100*80*39 |
| #5 | IPS-DTDC9-36S278 | 9~36VDC to 27VDC 8A | It can charge 24V lithium battery | 100*80*39 |
| #6 | IPS-DTDC18-36S2720 | 18~36VDC to 27VDC 20A | It can charge 24V lithium battery | 100*80*39 |
| #7 | IPS-DTDC9-36S288 | 9~36VDC to 28VDC 8A | It can charge the 24V storage battery | 100*80*39 |
| #8 | IPS-DTDC18-36S2820 | 18~36VDC to 28VDC 20A | It can charge the 24V storage battery | 100*80*39 |
| #9 | IPS-DTDC12S29.220 | 12V-29.2V 20A | Applicable to lithium iron LiFePO4 battery | 220*130*50MM |
| #10 | IPS-DTDC12S29.230 | 12V-29.2V 30A | 220*130*50MM | |
| #11 | IPS-DTDC12S29.240 | 12V-29.2V 40A | 220*156*65MM | |
| #12 | IPS-DTDC12S29.410 | 12V-29.4V 10A | Applicable to ternary lithium battery | 118*80*28MM |
| #13 | IPS-DTDC12S29.420 | 12V-29.4V 20A | 220*130*50MM | |
| #14 | IPS-DTDC12S29.430 | 12V-29.4V 30A | 220*130*50MM | |
| #15 | IPS-DTDC12S29.440 | 12V-29.4V 40A | 220*156*65MM | |
| #16 | IPS-DTDC12S5810 | 12V-58V 10A | Charging 48V lithium battery | 150*130*50MM |
| #17 | IPS-DTDC12S5820 | 12V-58V 20A | 220*130*50MM | |
| #18 | IPS-DTDC12S5830 | 12V-58V 30A | 220*156*65MM | |
