Basic Info.
Product Description
| Rated power | DC 60KW | DC 80KW | DC 120KW | DC 160KW | DC 200KW | DC 240KW | |
| Product model | TXDC380A60 | TXDC380B80 | TXDC380B120 | TXDC380B160 | TXDC380B240 | ||
| Electrical equipment | Installation method | Floor standing | |||||
| Overall dimensions | 80 * 55 * 1300 (mm) wide, thick, and high | 70 * 40 * 1900 (mm) wide, thick, and high | 70 * 40 * 1900 (mm) wide, thick, and high | 70 * 60 * 1900 (mm) wide, thick, and high | 70 * 60 * 1900 (mm) wide, thick, and high | 70 * 60 * 1900 (mm) wide, thick, and high | |
| Output mode | Single circuit, national standard connecting line, 5M cable | Two-way, national standard connecting line, 5M cable | |||||
| interface | 7-inch LCD touch screen | ||||||
| Wiring mode | Down in and up out | ||||||
| input voltage | AC380V±20% | ||||||
| Input frequency | 45-65Hz | ||||||
| output voltage | 200-1000V | ||||||
| Single gun output current | 0-250A | ||||||
| Input current | 110 | 148 | 220 | ||||
| Metering accuracy | Level 0.5 | ||||||
| Electrical indicators | Current limiting protection | ≥110% | |||||
| Voltage stabilization accuracy | ≤±0.5% | ||||||
| Steady current accuracy | ≤±1% | ||||||
| Ripple coefficient | ≤±0.5% | ||||||
| efficiency | ≥94.5% | ||||||
| power factor | ≥ 0.99 (above 50% load) | ||||||
| functional design | interface | 7-inch LCD color touch screen, LED indicator | |||||
| Charging mode | Automatic charging, fixed power, fixed amount, and fixed time | ||||||
| Payment method | Swipe card payment, small program scanning code payment | ||||||
| Communication method | Ethernet, 4G (optional) | ||||||
| safety design | Executive standards | GB/T 20234,GB/T 18487,GB/T 27930,NB\T 33008 | |||||
| Safety function | Charging gun temperature detection, overvoltage protection, undervoltage protection, overload protection, short circuit protection, grounding protection, overtemperature protection, low-temperature protection, insulation detection protection, polarity reversal protection, lightning protection, emergency stop protection, and leakage protection | ||||||
| Environmental indicators | working temperature | -25ºC-+50ºC | |||||
| Operating humidity | 5% - 95% frost free | ||||||
| Working altitude | <2000 meters | ||||||
| Protection level | IP54 | ||||||
| Cooling method | Forced air cooling | ||||||
| noise control | ≤600dB | ||||||
FAQ
Q1:Are you a factory or trading company?
A: We are a professional manufacturer of energy applications for over 23 years. And we are ev charger one-stop service supplier.
Q2: How about your delivery time?
A: Generally, it will take 15-30 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q3:How can we guarantee quality?
A: 1. We have a professional R & D team and assembly team, professional and technical staff.
2. Our products will be professionally inspected one by one before leaving the factory.
3. We also test 100% before delivery.
Q4: How do you make our business long-term and good relationship?
A: 1. We keep good quality and competitive price to ensure our customers benefit .
2. We will continue to improve technology to ensure that our products can keep up with social needs.
3. Our after-sales team will provide professional after-sales service in a timely manner.
Q5. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures. We also support ODM and OEM.
Q6: What is your terms of payment?
A: Alibaba online fast payment, T/T, L/C,etc.
