Basic Info.
Model NO.
FN-2000-12.6
Type
Lithium-Polymer Battery Charger
Charging Type
Electric Charger
Principle
Full Bridge Charger
Product Name
Fn-2000W-12.6
AC Input Voltage
110VAC 220VDC
Frequency
47-63Hz
Output Power
2000W
Output Voltage
12.6V
Output Current
100A
Product Net Weight
3.4kg
Transport Package
Paper Carton
Specification
290*159*94
Trademark
funelec
Origin
China
HS Code
8504401400
Production Capacity
10000 Units/Year
Packaging & Delivery
Package Size
290.00cm * 159.00cm * 94.00cm
Package Gross Weight
3.400kg
Lead Time
1 days (1 - 10 Pieces)
2 days (11 - 50 Pieces)
3 days (51 - 100 Pieces)
To be negotiated ( > 100 Pieces)
2 days (11 - 50 Pieces)
3 days (51 - 100 Pieces)
To be negotiated ( > 100 Pieces)
Product Description
Please pay attention to the compatibility of the charger.Stay away from
explosive gases and flammable materials.Follow the product manual for
correct use.Eliminate safety hazards.
| Parameters Table | |||
| product name | FN2000 Battery charger | Brand | FUNELEC |
| model | FN-2000-12.6 | Frequency | 47~60Hz |
| AC input voltage | 220VAC | Net weight | 3.3KG |
| 110VAC | |||
| DC output voltage | 12.6V | DC output current | 100A |
| Size | 290*159*94mm | Shell material | Steel plate |
| shell color | yellow | Efficiency | ≥88% |
| Applicable battery type | 3S 12.6V lithium battery | ||
| (S = Tandem) | |||
| Charging mode | Three-stage intelligent charging mode: constant current ~ constant voltage ~ trickle (floating charge) | ||
| Make sure the battery is fully charged (float charging is when a lead acid charger is used) | |||
| Charging indicator | Red and green two-color indication, red light means charging | ||
| Green light indicates fully charged or standby | |||
| Working conditions | Working environment temperature: -20~+40ºC; Relative humidity: 5~95%; | ||
| Maximum altitude: 12000 meters | |||
| Storage conditions | Storage environment temperature: -40~+70ºC; Relative humidity: 0~95%; | ||
| Maximum altitude: 20000 meters | |||
| Multiple protection | Over current, over voltage, over temperature, short circuit, reverse polarity, | ||
| Trickle or anti-backfill | |||
| Product advantages | 1. Safety certification CE, RoHS, FCC directive compatible, intelligent IC control, CC, CV | ||
| Float /Cut-off rickle automatic conversion to meet the needs of different curves. | |||
| 2.Steel plate shell, sturdy, elegant, safe, stable and reliable. | |||
| 3. Affordable. | |||
| It has an integrated MCU and PWM for power control. | |||
| Package Contents | * 1x battery charger | ||
| * 1x AC power cord | |||
| * 1x User Manual (Product Instruction Manual) | |||
