Basic Info.
Model NO.
BP-HP-10KWH-A
Installation
Packaged
Rechargeable
Chargeable
OEM/ODM
Customized OEM ODM Battery
Cathode Material
LiFePO4
Capacity
200ah
Warranty
15years
Transport Package
Sea
Trademark
bloopower
Origin
China
Product Description
| NO | Item | SPEC | Remark |
| 1 | Rated Capacity | 200AH | |
| 2 | Rated Voltage | DC-51.2V | |
| 3 | Rated Energy | 10240wh | |
| 4 | Operating Voltage | 44.8V~58.4V | 2.8V~3.65V |
| 5 | Max. Charge Current | 100A | 0.5C |
| 6 | Max. Discharge Current | 100A | 0.5C |
| 7 | Peak Current | 200A | |
| 8 | Ip Grade | IP20 | |
| 9 | Discharge Temp | -10ºC~55ºC | |
| 10 | Charge Temp | 0ºC~55ºC | |
| 11 | Dimension | L580mm*W800*H210mm | |
| 12 | Weight | 90Kg | |
| 13 | Internal Resistance | ≤30mΩ | |
| 14 | Cycle Life | 6500 | 25ºC |
| 15 | Communication | CAN/RS232+RS485 |
Product Description
One energy storage device that stores extra solar energy for later use is a home battery for solar systems.
In order to supply your home with dependable and green energy, it is made to integrate perfectly with your solar panel installation.
In order to supply your home with dependable and green energy, it is made to integrate perfectly with your solar panel installation.
Battery application
Solar System Lithium Battery Features
Easy installation, just like installing an upright air conditioner,TV,or refrigerator.
The working mode can be automatically adjusted, and it supports off-grid operation.
The module can be expanded within limited power and capacity.
The stored electric capacity has memory. Ordinary batteries lose their charge over time,
but lithium battery can be used at any time without affecting their capacity.
Intelligent management system.
Battery installation
Product qualification
Our solar battery have obtained various safety certifications, including UN38.3, CE, FCC, and R Ohs.
Packing
Factory Introduction There are more than 15,000 square meters production workshop, more than 200 employees.More than 20 outstanding technical experts, more than 20 international sales, accumulating rich research and development, production and testing experience and mature customized services.
You might also like
FAQ
Is there a minimum order quantity requirement?
No.order one and we can also sell
What is the estimated delivery time for your batteries?
The delivery time for the batteries ranges from 5 to 25 working days after the receipt of the advance payment. The exact delivery timeline will depend on the products ordered and the quantity of the order.
Does the wall mounted battery including inverter?
No, is battery only, so it is more flexible to work with different brand of inverter preferred by customer.
Is it possible for me to install the energy storage system at home by myself?
Yes, you may install the battery following our installation instructions. Please make sure to read the instructions thoroughly before beginning the installation process.
Is it possible for a Power wall to power a house?
A Power wall can certainly provide power to a home during a blackout or overnight. By pairing a Power wall with on-grid solar panels, you can significantly reduce your electricity bills by covering a substantial portion of your energy needs both during the day and night.
Is there a warning function for low battery levels in the battery?
The battery can be equipped with an early warning function, providing real-time monitoring of battery parameters and prompt notifications to users for timely resolution of any issues.
How do I activate the battery?
Before utilizing your battery for the first time, it is important to activate it by charging and discharging with a current greater than 1A, and to measure the terminal voltage to confirm it is functional. To prolong the battery's lifespan, it is recommended to disconnect it from the system before prolonged storage. After 24 hours, the battery will enter its automatic mode.
Is there customer support available for batteries?
Our company offers various channels for customer support, including through messaging platforms such as WhatsApp, Skype, and WeChat, as well as email. If you encounter any issues with your battery after purchase, we are available for video calls and, if needed, our engineers can even travel overseas to provide on-site assistance.
