Product Description
our company specialized in the manufacture and export of electric system products , including,pure sine wave power inverter, motor controller,charger,DC-DC converter,electronic throttle,battery discharge indicator,hour tachometer ,air conditioning system,electric system solution .BMS,etc
Product characteristics
Soft switching technology, maximum efficiency > 93%.
With APFC function, Power factor > 0.98.
CAN communication function (optional)
12V5A Auxiliary power supply (optional).
Working Temperature Range of Wide Temperature Range.
Strong protection function.
100% full load aging test.
Seismic grade of automobile grade.
Intelligent temperature compensation for batteries (lead-acid batteries)
function |
| function |
|
1. Overcurrent limit | √ | 6. Full automatic shutdown | √ |
2.Reverse connection protection | √ | 7.Anti-Walking Function (initial value Normally closed type) | √ |
3.Temperature protection | √ | 8. LED Indicator for Charging Process | √ |
4. Short-circuit protection | √ | 9. Temperature compensation (Not Used on Lithium Batteries) | √ |
5. Timing shutdown | √ | 10. CAN communication | √ |
Serial number | Project | Technical index |
1 | working temperature | -40ºC-+60ºC |
2 | Storage temperature | -40ºC-+90ºC |
3 | Relative humidity | 5%-95% |
4 | Heat dissipation mode | Forced air cooling |
5 | Input voltage | 90-265VAC |
6 | Input frequency | 50Hz±2% |
7 | Protection level | IP67 |
Model | Applicable battery voltage(lithium battery) | Maximum Charging Voltage | Maximum charging current |
SMCZ2-2435A | 24V | 30V | 35A |
SMCZ2-2440A | 24V | 30V | 40A |
SMCZ2-4825A | 48V | 60V | 25A |
SMCZ2-4830A | 48V | 60V | 30A |
SMCZ2-4835A | 48V | 60V | 35A |
SMCZ2-6025A | 60V | 75V | 25A |
SMCZ2-6030A | 60V | 75V | 30A |
SMCZ2-7220A | 72V | 90V | 20A |
SMCZ2-7225A | 72V | 90V | 25A |
SMCZ2-8425A | 84v |
| 25A |
SMCZ2-9615A | 96v |
| 15A |
SMCZ2-113.4-15 | 113.4 | 113.4 | 15A |
SMCZ2-116.8-15 | 116.8 | 116.8 | 15A |
|
|
|
